3BSE024398R1 ABB Interface Module

3BSE024398R1 Basic Info
Brand:ABB
Model:3BSE024398R1
Order PN:3BSE024398R1
Product Name:Symphony Plus DCS Bus Interface Module
Origin:Sweden
HS Code:85389091

Physical Parameter
Dimension(W×H×D):32mm×234mm×218mm
Net Weight:0.82kg; Gross packing weight≈1.13kg
Operating Temp:0℃~+60℃; Storage:-40℃~+70℃; IP20 front panel protection
Input & Output Spec
Power Input
DC24V nominal input (DC20~32VDC working range), max consumption 11W, dual redundant power access design
Signal Input
1. Backplane bus input: Proprietary high-speed differential bus signal from DCS main CPU rack
2. Digital DI input:4-channel passive dry contact input for cabinet door interlock & auxiliary status collection
Signal Output
1. Redundant fieldbus output for remote I/O rack connection, max transmission distance 1200m with shielded cable
2. LED indicator output: Power/RUN/FAULT/BUS status lamp indication
3. Alarm relay output: Single SPST dry contact(250VAC/3A) for central fault remote alert

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
