3BSE011180R1 SE071005AK PM511V08 ABB processor module

ABB PM511V08 (3BSE011180R1, SE071005AK)
Product Introduction
The ABB PM511V08 (Part Numbers: 3BSE011180R1, SE071005AK) is a  processor module belonging to ABB’s Advant OCS / AC500 series industrial automation control systems. It serves as a core central processing unit (CPU) for complex industrial control applications, including process automation, power generation, manufacturing, and machinery monitoring. This module delivers robust data processing, reliable system control, and seamless communication with field devices, I/O modules, and higher-level supervisory systems, ensuring stable operation and efficient execution of control algorithms in demanding industrial environments.

Technical Parameters
Brand: ABB (ASEA Brown Boveri)
Model: PM511V08; Part Numbers: 3BSE011180R1, SE071005AK
Weight: 0.76 kg (approximate)
Dimensions: 274.5 mm × 270 mm × 27 mm (L×W×H)
Country of Origin: Sweden
HS Code: 8538900000
Operating Temperature: -25°C to +55°C
Storage Temperature: -40°C to +85°C
Power Supply: 5 V DC (typical 4900 mA, max 6000 mA); 24 V DC (typical 200 mA, max 280 mA)
Power Dissipation: Typical 25 W
Processor: Motorola 68040, 25 MHz clock speed

Memory: 8 Mbyte Dynamic RAM with ECC (Error Correction Code); PCMCIA slot for flash memory card expansion
Input: Integrated with Future Bus+ and S100 I/O interfaces for connection to field sensors, analog/digital input modules, and control devices
Output: Configurable digital relay outputs and analog signal outputs (4–20 mA, 0–10 V DC) for alarm signaling and control actuation; supports communication-based output to DCS/PLC systems
Communication Interfaces: RS-232, CAN bus, Future Bus+; compatible with PROFIBUS DP, Modbus RTU, and other industrial protocols for system integration
Key Features: High-speed data processing with ECC memory for error resilience; hot-swappable design for maintenance; front-panel LED status indicators (Power, Run, Fault, Communication); robust industrial-grade construction; CE, UL, CSA, and RoHS compliant; supports redundant processor configuration for enhanced system reliability

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
