204-040-100-012 VM600 VIBRO METER protection and condition monitoring module

Vibro-Meter VM600 (204-040-100-012)
Product Introduction
The Vibro-Meter VM600 (Part Number: 204-040-100-012) is a  machinery protection and condition monitoring module, part of the renowned VM600 series by Meggitt Sensing Systems. It is engineered for critical industrial applications including power generation, oil & gas, petrochemical, and marine sectors, delivering precise vibration, speed, and process parameter monitoring for rotating machinery such as turbines, generators, compressors, and pumps. This module serves as a core component for real-time data acquisition, signal processing, and system communication, enabling predictive maintenance and ensuring equipment reliability and safety.

Technical Parameters
Brand: Vibro-Meter (Meggitt Sensing Systems)
Model: VM600; Part Number: 204-040-100-012
Weight: 0.4 kg (approximate)
Dimensions: 267 mm × 133 mm × 25 mm (W×H×D, standard 19-inch rack-mountable)
Country of Origin: Sweden (Europe)
HS Code: 9031800000 (for industrial monitoring and measuring equipment)
Operating Temperature: -20°C to +70°C
Storage Temperature: -40°C to +85°C
Power Supply: 24 V DC (rack-powered via VM600 backplane)
Input: 16 dynamic analog input channels (compatible with IEPE/ICP vibration sensors); 4 speed input channels; supports vibration, displacement, and speed signal inputs
Output: Configurable analog outputs (4–20 mA, 0–10 VDC) and digital relay outputs for alarm and control signaling; up to 20 processing outputs per dynamic channel
Communication Interfaces: RS-485 (Modbus RTU compatible); integrates with VM600 system backplane for internal communication; compatible with VibroSight monitoring software
Data Acquisition: 24-bit high-resolution ADC; simultaneous sampling on all channels (asynchronous fixed-frequency or synchronous sequential tracking); sampling rate up to 51.2 kHz per channel; high-resolution FFT up to 6400 lines per 500 ms
Frequency Response: 0.1 Hz to 10 kHz

Vibration Measurement Range: 0 to 50 mm/s
Key Features: High-precision 24-bit data acquisition with excellent SNR; multi-channel simultaneous monitoring; wide operating temperature range for harsh industrial environments; robust industrial-grade construction; hot-swappable design for easy maintenance; front-panel LED status indicators; seamless integration with VM600 system racks and VibroSight software; CE and RoHS compliant

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
