Allen‑Bradley TLY‑A230T‑HK64AA – Product Specification & Description
Brand: Allen‑Bradley (Rockwell Automation)
Model: TLY‑A230T‑HK64AA
Product Name: TL‑Series Compact Servo Motor
Dimensions: 70 mm (2.75 in) bolt circle (NEMA 23 frame)
Weight: Approx. 2.0 kg (4.41 lb)
Country of Origin: Mexico
HS Code: 850164
Operating Temperature: 0°C to +40°C (standard); extended to -20°C to +65°C for storage
Protection Rating: IP65 (dust‑tight & water‑resistant housing; no shaft key, no shaft seal)
Input Power: 230 VAC, 3‑phase, 50/60 Hz
Speed: Rated 6000 rpm; max 6000 rpm
Torque: Continuous 1.16 Nm (10.3 lb‑in); Peak 3.05 Nm (27.0 lb‑in)
Power Rating: 0.44 kW continuous (S1 duty cycle)
Feedback: Incremental encoder, 2000 lines/revolution; A/B quadrature signals + index
Connection: Circular connectors with 1 m (39.4 in) cable; metric mounting
Brake: Integral 24 VDC holding brake; typical release time <73 ms; holding torque ~1.24 Nm (11 lb‑in)
Key Features:
Low‑inertia, high‑torque‑density design for compact industrial motion control;
IP65 ruggedness for harsh environments; 24V DC brake option for secure positioning;
high‑speed response up to 6000 rpm;
compatible with Kinetix 5100/5300 servo drives and Ultra 3000 (2098) series drives ;
CE, UL, and RoHS compliant;
onboard motor ID for auto‑configuration; conformal coating option for enhanced durability
